High Quality 3000 Watt Low Frequency Solar Inverter Charger
This is the 3000 Watt with a 9000 Watt Peak Low Frequency Solar Power Inverter Charger. Long name, yes, but with as many features as this thing has, no other name will do! This inverter has a 60 amp solar charge controller that will take up to 7 of our 120 watt solar panels directly into it.
ORDER ONLINE NOW OR CALL (866) 606-3991
Features:- 3000 watt low frequency inverter
- 9000 watt surge for 20 seconds -3x surge capability
- Battery Priority Selector
- Terminal Block
- GFCI
- Marine Coated and Protected
- Multi Stage Smart charger 65 Amp
- 60 amp MPPT solar charge controller - PV in 15-30Vdc
- remote panel available
- auto gen start
- auto frequency
- 10msec typical transfer time
- optional 25W power save mode
- 7 battery type settings for charger

ORDER ONLINE NOW OR CALL (866) 606-3991
Specifications:
Inverter Output Specifications:
Continuous Output Power: 3000 Watts Surge Rating: 9000 Watts (20 Seconds) Output Waveform: Pure Sine/Same as input (Bypass Mode) Output Voltage 100-110-120Vac Nominal Efficiency: >88% (Peak) Line Mode Efficiency: >95% Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz Typical Transfer Time: 10ms (Max) THD: < 10% DC
Input Specifications
Nominal Input Voltage: 12.0Vdc Minimum Start Voltage: 10.0Vdc Low Battery Alarm: 10.5Vdc-11.0Vdc Low battery Trip: 10.0Vdc-10.5Vdc High Voltage Alarm: 16.0Vdc Low battery Voltage Restart: 15.5Vdc Idle Consumption: 6 amps DC Power Saver Mode Idle Consumption: <2.3 amps AC
Charger Specifications
Output voltage: Depends on battery Type Charger Rate: 65A
Solar Charge Controller Specifications
Rated Voltage: 12V Input Voltage Range: 15-30Vdc Rated Charge Current: 60A Max DC Load: 15A No Load Current: < 10mA Bulk Charge: 14.5V (default) Floating Charge: 13.5V (default) Equalization Charge: 14.0V (default)
Dimensions
Unit Weight: 64 lbs. Unit Size L x W x H: 23.54 x 8.59 x 7.05 inches Shipping Weight: 68 lbs. Shipping L x W x H 29.13 x 12.40 x 11.81 inchesORDER ONLINE NOW OR CALL (866) 606-3991
|
|
 |
 |
 |
 |
|
 |

|
